LINEAR ACTUATOR

A better solution for controlling gear doors
HighlightsTechnical specifications
InstallationGO TO THE SHOP

Highlights

STRONG LINEAR TORQUE

Thanks to the design of Electron Retract’s Linear Actuators, they provide a level of linear torque that is unmatched by conventional servos or pistons.

QUALITY AND RELIABILITY ABOVE ALL ELSE

Just like our retracts, our Linear Actuators are milled from solid 7075 T6 aviation grade aluminium, before being anodised and laser engraved.

EXTENSIVE OPTIONS TO SUIT YOU

Three lengths are available, as well as being able to choose between High Speed, or even Higher Torque.

INCLUDED MOUNTING BRACKET AND ANGLES

Thanks to the multiple mounting points on the actuator itself and thanks to the provided mounting bracket, any number of different deflection angles can be achieved in order to match your requirements exactly.

Technical specifications

Weight:
35g
Voltage:
4,5 to 6v
Maximum drain:
1,1A
Cycle time:
2,5 to 4,5 seconds depending on voltage and door weight
Connector:
Same as servo.
Includes:
Actuator, three position mounting bracket and preinstalled ball link.
Stroke:
20mm, 25mm or 30mm. (tolerance +- 1mm)
It is not possible to set mid points, only open, closed or shutoff due to overload are available.
Versions:
High Torque:  60N at 6v, in 3,5s (50N at 5,5v in 4,5s)
High Speed:    45N at 6v, in 2,5s (35N at 5,5v in 3,5s)

Installation

ANY QUESTIONS? DON'T WORRY, WE'RE TO HELP YOU!

Electron-Retracts Technical Service

We provide information, guides and videos to assure a correct installation and operation of our products.

Additionally, our dedicated support team can offer assistance at any point of your build or setup as well as answering any queries along the way.
